Electric Motor With Variable Speed Drive Variable Speed Electric Motor 0.37 KW

Y2 series three-phase asynchronous motor installation size and power grade in conformity with relevant

standards of IEC and Germany DIN42673 standard line and Y series motor, its shell protection grade for

IP54, cooling method for IC41l, operate continuously (S1). Using F insulation class and grade B assessment

according to temperature (except for 315 L2-2, 4355 all specifications F grade the assessment, and ask the

assessment load noise index.

Y2 series three-phase asynchronous motor the rated voltage is 380 V. rated frequency is 50 Hz. 3 KW

the following connection is Y , other power are delta connection . Motor running the place at no more than

1000 m; Environment air temperature changes with seasons, but no more than 40 °C; Minimum

environment air temperature is-15 °C; The wet month average high relative humidity is 90%; At the same

time, this month is not higher than the lowest average temperature 25 °C.

It can be widely used in driving principal axis of CNC machine tools, weaving, chemical industry, printing,

plastic, metallurgy and other automatic control. The motor adopts independent ventilation cooling structure,

so it has good cooling effect at different speeds
